Road Stream Crossing Site E21

Maple River Watershed, Tributary to East Branch Maple

Douglas Lake Rd

McKinley Twp, Emmet County

GPS Coordinates: 45.57284794 , -84.75714698

T37N R04W Sec 26

Road Width at Culvert: 22 ft.

Road Surface: Paved

Maintenance: year around

Low Point: At Stream

Existing Drainage Control? no

Any Failings? no

Type of Crossing: culvert(s) (twin culvert)

Is this crossing constricted? no

Are there adjacent wetlands? no

Comments: does not appear as though water has flowed through here for some time

Length: 0 ft.

Slope: 0%

Vegetation: partial

Length: 0 ft.

Slope: 0%

Vegetation: partial

Length: 30 ft.

Diameter: 24 ft.

Material: galvanized

Condition :poor

Flow: clear

Fill Depth: 3 ft.

Embankment Slope: 1:1

Fill Depth: 3 ft.

Embankment Slope: 1:1

Stream Width: 0 ft.

Stream Depth: 0 in.

Stream Current: none

Stream Substrate: sand,gravel

Stream Width: 0 ft.

Stream Depth: 0 in.

Stream Current: none

Stream Substrate: sand,gravel

Is there Streambank erosion beside the crossing? no

Is there embankment erosion? no

Is there erosion at the culvert outlet? no

Is there erosion at the shoulder and/or ditch? no

Is there pooling at the outlet? no

Is there sand over the crossing? no



Extent of Erosion: minor

Action Recommended? yes

Add pavement? no

Add paved raised edge? no

Number of erosion control structures: 0

Number of sediment basins: 0

Number of diversion outlets: 0

Increase fill? no

Replace culvert(s)? no

Dimensions of replacement: 0

Extend culvert(s)? no

Lineal feet to extend: 0
